| Model |
PM1000TV-4K |
| LCD panel |
Panel Brand |
CMO |
| Diagonal Size |
100" |
| Aspect Ratio |
16:9 |
| Pixel pitch |
0.5737mm×0.5737mm |
| Response |
8ms |
| Resolution |
3840×2160 |
| Contrast Ratio |
4000:1 |
| Brightness(cd/m2) |
500cd/m2 |
| Display area |
2203.2(W)×1239.3(H)mm |
| Color |
16.7 Million color |
| View Angle |
H:89o/89o V:89o/89o |
| Input/Output port |
Video |
1*HDMI2.0,1*HDMI1.4,1*HDMI(MHL),AV*2,VGA*1 |
| Audio |
SPDIF*1,20W speaker |
| Other |
2* USB2.0,2* USB3.0,RJ45*1,SD*1,WIFI*1 |
| Tech Features |
Language |
Chinese,English and other |
| CPU |
ARM A53,4core |
| GPU |
Mali450MP4 (4+2) 600MHz |
| OS system |
Android 5.0 |
| Memory |
2G |
| Storage |
8G |
| Video Format |
PAL,NTSC |
| Frequency |
Horizontal Frequency:20 ~ 82KHz(Anolog&Digital)
Vertical Frequency:55~75Hz |
| Optimum Resolution |
3840x2160 @ 30HZ |
| Support resolution |
3840x2160;1920x1080;1680x1050;1600x1200;1440x1050;1360x768;1280x1024;1280x768; 1024x768;832x624; 800x600;720x400; 600x480; |
| Video format |
480i;480p;576i;576p;720p;1080i;1080p,4K |
| Function Features |
EMC |
Total EMC metal cover material, Antistatic, Anti magnetic |
| Protection |
Toughened Glass protect fron panel, Metal chasis and aluminum frame |
| USB play format |
MPEG1,MPEG2PS,MPEG2TS,AVCHD,MP4Part10,MP4Part2,AVI(XVID),AVI(MotinJpeg),MOV,WMV,MKV,RMVB,WEBM,3GPPUSB,MP3,WMA,WAVUSB, JPEG,MPO |
| Sysnc Project |
iPhone,iPad,Android phone/table, Windows PC sysnc on TV |
| None Noise |
Full body head dissipation, None fan build in, None noise |
| Image Adjust |
Support auto image, color adjustment |
| View Mode |
Support multiple view mode, such as: normal, dynamic etc |
| Image quality |
3D noise reduction,3D signal wave filtering |
| Energy save |
LED backlight to save 50% power consumption than other display type |
| Standby |
Auto enable standby mode after few seconds no signal |
| Sunlight readable |
Frosted LCD skin to make sunlight readable |
| View angle |
Full view angle, Up/Down/Left/Right visual |
| Response |
6.5ms fast response time |
| Pixel protect |
Display no blur and no flash |
| Long life |
7x24hrs working, 60,000hrs life time |
| Physical Features |
Body material |
Total Metal body,Toughened glass, Aluminum front frame |
| Color |
Black |
| Temperature |
Work: 0°C ~50°C ; Storage:-20° ~ 60°C |
| Humidity |
Work: 10% to 90% (Non Condensing) ; Storage: 0 to 95% (Non Condensing) |
| Noise |
Working<50dBA |
| Product Dimension |
2275mm(W)x1311mm(H)x88mm(D),without wall mount bracket or floor stand set |
| Power |
AC 100~240V~/2~5A/ 60-50Hz |
| Consumption |
Max≤550W;Normal≤450W;Standby≤5W |
| Weight |
NW:130Kg±0.5Kg; GW:170KG±0.5Kg |
| Package Dimension |
2530mm(W)x1740mm(H)x420mm(D) |
| Other |
Accessories |
Quick start guide,Warranty card,Remote controller,Power Cord,Wall mount bracket |
| Option |
HDMI cable,DVI cable,VGA cable,BNC cable;Floor stand set |
| Certification |
RoHS,CCC,CNAS,CE,FCC,ISO9001,Software patent |
| Warranty |
13 months |
